19″ Server Rack Enclosures — Deep-Frame Galvanised Steel Cabinets for Data Centres, Enterprise IT & High-Density Compute

1000 mm & 1200 mm deep server cabinets • High-airflow mesh doors • Welded or flat-pack • Manufactured in Noida, India

Eterna server rack enclosures are purpose-built for deep-frame server hardware, blade chassis, and high-density storage arrays that demand the extra depth standard data racks cannot provide. Available in 1000 mm and 1200 mm depths, these cabinets accommodate full-size rail kits from Dell, HPE, Lenovo, Supermicro, and all major server manufacturers — with room behind the rear posts for cable management, PDUs, and proper airflow clearance. Constructed from galvanised steel with 65–85% airflow mesh doors, three-point lever-latch locking, fully adjustable 19″ EIA-310-E mounting profiles, and a vented top panel for overhead cable entry.

The range spans 12U to 47U heights in 600 mm and 800 mm widths, covering everything from a compact edge deployment to a full-height data centre row. Available welded (fully assembled) or flat-packed for freight-efficient shipping to site, with a choice of single-piece mesh, wardrobe-style split mesh, or tempered glass door configurations. Every cabinet ships with an earthing strip as standard, transport castors, and access to a full range of complementing accessories — shelves, blanking panels, PDUs, fan trays, and vertical cable management. Manufactured in our vertically integrated Noida facility with custom colours, OEM branding, and non-standard sizing available for volume rollouts.

12U – 47U heights 600 / 800 mm widths 1000 / 1200 mm depths 65–85% mesh airflow GI Steel galvanised 3-point locking Welded or flat-pack 18 models in range

Need a quote for server rack enclosures?
Tell us U-height, width, depth, door type, quantity, and delivery location — we respond within 24 hours.

Request Quote Email Requirements

Get a Quote Photo Gallery

Typical Applications

Data Centres / Comms Rooms 19″ Server Equipment Communication Systems Blade Chassis & Storage Arrays Cloud & Colocation UPS & Power Distribution Edge Computing

Enclosure Features

Lever Latch Lock — Three-Point LockingErgonomic lever handle with simultaneous top, middle, and bottom latching. Key-lockable for restricted access to server hardware.

65–85% Airflow Mesh DoorsHigh-density perforated mesh for maximum front-to-rear airflow. Single-piece mesh, wardrobe-style split mesh, or tempered glass options available.

Fully Adjustable 19″ Mounting ProfilesFront + rear rail pairs per EIA-310-E. Depth-adjustable for 1000 mm & 1200 mm server rail kits. Compatible with Dell, HPE, Lenovo, Supermicro, and all major OEM rails.

Vented Top with Cable EntryPerforated top panel for heat exhaust and overhead cable routing. Brush-strip or grommet cable entry options for clean containment.

Full-Length Vertical Cable ManagementOptional integrated cable troughs on both sides. Keeps power and data cables organised and separated for optimal airflow paths.

Earthing Strip (Standard)Bonded earth bar fitted as standard. Multiple earth points for rack-mount equipment grounding per data centre compliance requirements.

Lockable Side Panels (Optional)Quick-release lockable side panels for row-end security or standalone deployment. Tool-free removal for maintenance access.

Transport Castors — Welded or Flat-PackCastor kit for easy positioning in data centre aisles. Available fully welded or flat-packed for freight-efficient delivery to site.

Full Range of Complementing AccessoriesShelves (fixed & sliding), blanking panels, PDUs, fan trays, cable rings, brush panels, and more — all designed for the EGS-SVR range.

The Eterna Advantage

Multiple Door Configurations+

Single-piece mesh for maximum airflow in hot aisle / cold aisle setups. Wardrobe-style split mesh for wide equipment access without full door swing clearance. Tempered glass front for visual monitoring. Solid steel rear for perimeter security. All doors reversible left/right hinge.

Bespoke Roof Options for Overhead Cabling+

Standard vented roof, or configure with brush-strip cable entry, multi-grommet panel, or fully open top for overhead cable tray environments. Cable entry cut-outs pre-positioned to match your facility’s cable pathway layout.

Custom Sizing Available+

Non-standard U-heights, modified depths, or wider frames for specialised server platforms. We manufacture custom dimensions through our NPI process — same quality, same lead time framework. Ideal for GPU compute racks, storage arrays, or high-density blade deployments.

Customer Colours & Finishes+

Standard finish is RAL 7021 (black grey) or RAL 7035 (light grey). Any RAL colour available for brand consistency across your data centre estate. Textured, semi-gloss, or matte finishes. OEM white-label with your branding, serial numbers, and documentation.

Galvanised Steel — Extreme Corrosion Resistance+

Constructed from galvanised steel with conveyorised pre-treatment and polyester powder coat. Delivers long-term corrosion resistance even in environments with elevated humidity or condensation — far superior to standard cold-rolled steel cabinets.

Vertically Integrated — Manufactured Under One Roof+

Laser cutting, CNC forming, welding, powder coating, assembly, QC, and dispatch all in our Noida facility. No sub-contracting. Full control over quality, schedule, and cost. Volume runs or single prototypes — same production line, same standards.

What’s Included & What’s Optional

Standard with every cabinet:

19″ Rails (front + rear) 3-Point Lever Latch Lock Mesh Front Door Vented Top Panel Earthing Strip Transport Castors Powder Coat Finish

Optional add-ons:

Lockable Side Panels Vertical Cable Management Glass Front Door Wardrobe-Style Mesh Door Fan Tray (2/4/6 fan) PDU / Power Strip Fixed / Sliding Shelf Blanking Panels Brush Strip Panel Levelling Feet Custom RAL Colour OEM Branding

Reference Tables

600 mm Wide — Specification & Ordering Chart (10 models)+

600 mm wide server enclosures. 1000 mm & 1200 mm depths. Specify door type and colour when ordering.

Product Code	U Height	Width (mm)	Depth (mm)
EGS-SVR-12610	12U	600	1000
EGS-SVR-12612	12U	600	1200
EGS-SVR-27610	27U	600	1000
EGS-SVR-27612	27U	600	1200
EGS-SVR-42610	42U	600	1000
EGS-SVR-42612	42U	600	1200
EGS-SVR-45610	45U	600	1000
EGS-SVR-45612	45U	600	1200
EGS-SVR-47610	47U	600	1000
EGS-SVR-47612	47U	600	1200

800 mm Wide — Specification & Ordering Chart (8 models)+

800 mm wide server enclosures for wider chassis and enhanced cable management space.

Product Code	U Height	Width (mm)	Depth (mm)
EGS-SVR-27810	27U	800	1000
EGS-SVR-27812	27U	800	1200
EGS-SVR-42810	42U	800	1000
EGS-SVR-42812	42U	800	1200
EGS-SVR-45810	45U	800	1000
EGS-SVR-45812	45U	800	1200
EGS-SVR-47810	47U	800	1000
EGS-SVR-47812	47U	800	1200

Custom U-heights (9U, 15U, 18U, 22U, 32U, 37U) and non-standard depths available through our NPI process.

Request a Quote for Server Racks →
